| Allmänt |
| Typ av enhet | Nätverksadapter |
| Formfaktor | Instickskort - låg profil |
| Gränssnittstyp (buss) | PCI Express 3.0 x8 / PCI Express 3.0 x4 |
| Version av PCI-specifikation | PCIe 3.0 |
| Nätverk |
| Portar | 25 Gigabit Ethernet x 2 |
| Anslutningsteknik | Kabelansluten |
| Datalänkprotokoll | 10 Gigabit Ethernet, 25 Gigabit Ethernet |
| Dataöverföringshastighet | 25 Gbps |
| Prestanda | Genomströmning i två riktningar: 100 Gbps
Bandbredd per port: 50 Gbps |
| Kapacitet | Jumboramstorlek: upp till 9,6 KB |
| Protokoll för administration på distans | SNMP |
| Statusindikatorer | Länk/akvititet |
| Funktioner | VLAN-stöd, stöd för IPv6, fullt duplexläge, TCP/IP-avlastning, Quality of Service (QoS), Jumbo Frames-support, IPv4-support, PXE-support, LACP-support, LLDP-support, Large Send Offload (LSO), Receive Side Scaling (RSS), UEFI-support, TCP Segmentation Offload (TSO), QoS-märkning, Extended Message-Signaled Interrupts (MSI-X), UDP/IP-offloading, TCP/IP-checksummeavlastning, RDMA over Converged Ethernet (RoCE), Virtual Extensible LAN (VXLAN), Network Virtualization using Generic Routing Encapsulation (NVGRE), RDMA over Converged Ethernet (RoCE) v2 |
| Standarder som följs | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.1ab (LLDP), IEEE 802.3az, IEEE 802.1Qbb, IEEE 802.1Qaz, IEEE 802.1Qau, IEEE 802.1Qbg, IEEE 1588v2 |
| Processor / Minne |
| Processor | 1 x Mellanox Technologies Mellanox ConnectX-4 Lx |
| Expansion/Anslutning |
| Gränssnitt | 2 x 25Gb Ethernet - SFP28 |
| Diverse |
| Standarder som följs | FCC klass A-certifierad, CISPR 22 klass A, ICES-003, EN55024, EN 60950-1, RoHS, ACA, cTUVus, BSMI Class A, VCCI Class A, EN 55022 Class A |
| Strömtillförsel |
| Energiförbrukning vid drift | 9.7 Watt |
| Programvara / Systemkrav |
| Operativsystem erfordras | SuSE Linux Enterprise Server 11, Microsoft Windows Server 2012, Oracle Solaris 11.1, Microsoft Windows Server 2012 R2, VMware ESXi 5.5, Ubuntu 14.04, Red Hat Enterprise Linux 7, Red Hat Enterprise Linux 6.6, Red Hat Enterprise Linux 7.1, Citrix XenServer 6.5, SuSE Linux Enterprise Server 12, Red Hat Enterprise Linux 6.7, Red Hat Enterprise Linux 7.2, VMware ESXi 6.0 |
| Tillverkarens garanti |
| Service och support | Begränsad garanti - 1 år |
| Miljöparametrar |
| Min temperatur vid drift | 5 °C |
| Max temperatur vid drift | 60 °C |
| Luftfuktighet vid drift | 5 - 95 % (icke-kondenserande) |
| Kompatibilitetsinformation |
| Designat för | HPE Apollo 4200 Gen10, 4200 Gen10 336TB Archive Node with 25Gb NIC for Qumulo, 4200 Gen10 for HPE Ezmeral Container Platform, 4200 Gen10 Qumulo Archive Node, 4200 Gen10 Qumulo Hybrid Node, 4200 Gen9 for Google, 4510 Gen10, 4530 Gen9
HPE ProLiant DL180 Gen10, DL180 Gen10 Entry, DL180 Gen10 SMB, DL325 Gen10 Base, DL325 Gen10 Solution, DL360 Gen10, DL360 Gen10 Base, DL360 Gen10 Entry, DL360 Gen10 High Performance, DL360 Gen10 Low, DL360 Gen10 Network Choice, DL360 Gen10 Performance, DL360 Gen10 SMB, DL360 Gen10 SMB Network Choice, DL360 Gen10 Solution, DL380 Gen10, DL380 Gen10 All Flash Server for Datera, DL380 Gen10 Base, DL380 Gen10 Entry, DL380 Gen10 Entry SMB, DL380 Gen10 for Cohesity DataPlatform, DL380 Gen10 High Performance, DL380 Gen10 Hybrid Server for Datera, DL380 Gen10 Network Choice, DL380 Gen10 Network Choice for CTERA, DL380 Gen10 NVMe All Flash Server for Datera, DL380 Gen10 Performance, DL380 Gen10 Server for CTERA, DL380 Gen10 SMB, DL380 Gen10 SMB Networking Choice, DL380 Gen10 Solution, DL388 Gen10 Network Choice, DL560 Gen10, DL560 Gen10 Base, DL560 Gen10 Entry, DL560 Gen10 Performance, DL580 Gen10, DL580 Gen10 Base, DL580 Gen10 Entry, DL580 Gen10 Performance, DL580 Gen9 Database, DL580 Gen9 SAP HANA Scale-out Base Configuration, DL580 Gen9 SAP HANA Scale-up Base Configuration, DX380 Gen10, DX560 Gen10, ML350 Gen10, ML350 Gen10 Base, ML350 Gen10 Entry, ML350 Gen10 High Performance, ML350 Gen10 Performance, ML350 Gen10 SMB, ML350 Gen10 Solution, ML350 Gen10 Sub-Entry, XL170r Gen10, XL170r Gen10 24TB Server for Cohesity DataPlatform, XL190r Gen10, XL190r Gen10 for HPE Ezmeral Container Platform, XL230k Gen10 Compute Tray, XL270d Gen10 for HPE Ezmeral Container Platform, XL270d Gen9, XL450 Gen10
HPE SimpliVity 325 Gen10 Node, 380 Gen10 G Node, 380 Gen10 Network Choice G Node, 380 Gen10 Network Choice H Node, 380 Gen10 Node
HPE StoreEasy 1660 Expanded Storage, 3850 Gateway Single Node |
|
