| Allmänt |
| Typ av enhet | Nätverksadapter |
| Formfaktor | Instickskort |
| Gränssnittstyp (buss) | LAN-on-motherboard (LOM) |
| Nätverk |
| Portar | 10 Gigabit SFP+ x 4 |
| Anslutningsteknik | Kabelansluten |
| Datalänkprotokoll | 10 Gigabit Ethernet |
| Dataöverföringshastighet | 10 Gbps |
| Kapacitet | Virtuella funktioner: 128 |
| Protokoll för administration på distans | RMON |
| Funktioner | Flödeskontroll, VLAN-stöd, wake on LAN (WOL), stöd för IPv6, Quality of Service (QoS), RDMA-support, Virtual Machine Device Queues (VMDq), PXE-support, Large Send Offload (LSO), Receive Side Scaling (RSS), UEFI-support, Single Root I/O Virtualization (SR-IOV), LACP (Link Aggregation Control Protocol), Energy Efficient Ethernet, Class of Service (CoS), märkt VLAN, Extended Message-Signaled Interrupts (MSI-X), TCP/IP-checksummeavlastning, UDP/IP-checksummeavlastning, Virtual Ethernet Port Aggregator (VEPA), Network Controller Sideband Interface (NC-SI), Virtual Extensible LAN (VXLAN), Network Virtualization using Generic Routing Encapsulation (NVGRE), Virtual Ethernet Bridge (VEB), TLP Processing Hint (TPH), Advanced Packet Filtering, Intel Virtual Technology (VT), stöd för Jumbo Frames (upp till 9728 byte) |
| Standarder som följs | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1as, IEEE 802.1Qbg |
| Processor / Minne |
| Processor | 1 x Inphi CS4223 |
| Expansion/Anslutning |
| Gränssnitt | 4 x 10Gb Ethernet - SFP+ |
| Diverse |
| Standarder som följs | ICES-003 klass A, RoHS, UL 60950-1 Second Edition, FCC Part 15 A, KCC Class A, VCCI Class A, RCM, RRA Class A |
| Programvara / Systemkrav |
| Medföljande programvara | Intel PROSet |
| Operativsystem erfordras | Microsoft Windows Server 2012 R2, SuSE Linux Enterprise Server 11 SP4, Microsoft Windows Server 2016, VMware ESXi 6.5, Red Hat Enterprise Linux 7.3, Red Hat Enterprise Linux 6.9, SuSE Linux Enterprise Server 12 SP2, VMware ESXi 6.0 update 3 |
| Tillverkarens garanti |
| Service och support | Begränsad garanti - 1 år |
| Kompatibilitetsinformation |
| Designat för | Lenovo ThinkAgile HX2320 Appliance 7X83
Lenovo ThinkAgile HX3321 Certified Node 7Y89
Lenovo ThinkAgile HX3520-G Appliance 7X84
Lenovo ThinkAgile HX7520 Appliance 7X84
Lenovo ThinkAgile HX7820 Appliance 7Y95, 7Z08
Lenovo ThinkAgile HX7821 Certified Node 7Y96, 7Z09
Lenovo ThinkAgile VX 1U Certified Node 7Y93
Lenovo ThinkAgile VX Certified Node 7Y94, 7Z12
Lenovo ThinkAgile VX3320 Appliance 7Y93
Lenovo ThinkAgile VX3520-G Appliance 7Y94
Lenovo ThinkAgile VX5520 Appliance 7Y94
Lenovo ThinkAgile VX7520 Appliance 7Y94
Lenovo ThinkAgile VX7820 Appliance 7Z13
Lenovo ThinkSystem SR630
Lenovo ThinkSystem SR650
Lenovo ThinkSystem SR850
Lenovo ThinkSystem SR860
Lenovo ThinkSystem SR950 |
|
